Air Plasma Cutting Machine
Welding EquipmentsThe prime consideration for Manual Hand plasma cutting machines is portability. The machine has good features like it can be used for a long time without any trouble and it saves electricity. Using this machine for small repair and maintenance jobs will give the best results.
From ₹
22,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| Particulars | Inverter Plasma Cutters | ||
| Model | Cut 40 | Cut 60 3P | Cut 100 I |
| Input Voltage (V) | 220V 15% | 380V 15% | 380V 15% |
| Phase | 1 | 3 | 3 |
| Frequency (HZ) | 50 / 60 | 50/60 | 50/60 |
| Rated Input (A) | 30 | 12 | 23.1 |
| No-load Voltage (V) | 230 | 240 | 268 |
| Output Current Range (A) | 15-40 | 20-60 | 20-100 |
| Base Material | Plate Thickness (mm) | Current Range (A) | Air Pressure | Applicable Model |
Carbon Steel, Stainless Steel, Low-alloy Steel |
0.8-15.0 | 20-40 | 3-4 | Cut 40 |
| 0.8-25.0 | 20-60 | 3-4 | Cut 60 | |
| 0.8-40.0 | 20-100 | 3-4 | Cut 100 |
