Vertical Bandsaw Machine For Saw Mill
Wood Working MachinesPathak is a leading brand manufacturing the best quality vertical bandsaw available with a wide blade mainly used to saw steel and other hard materials. At the same time, the Vertical Band saw is used for soft plastics, wood, and non-ferrous metal alloys made with the latest technology provides the latest features demanded by the consumer, makes it more efficient and provides long functional life.
Features
- Dynamically balanced and precisely machined Band wheels for high performance
- Finely machined heavy Cast Iron table
- Double blade guide with roller support from back
- CNC machined Bearing pedestals for longer bearing life
- Steel body structure
Application
- Sawing/cutting Wood
- Plastic Polymers
- Fly Ash Blocks
- Aluminum
From ₹
165,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model No | JV24 | JV30 | JV36 | JV42 | JV48 |
| Diameter Saw Wheel | 24' | 30' | 36' | 42' | 48' |
| Width Wheel | 2” | 2.5” | 3" | 3' | 3' |
| Work Table Size | 24"x24" | 30"x30" | 42"x42” | 42”x42" | 42"x42" |
| Blade Length | 16ft | 18 ft | 19.5 ft | 23 ft | 25.5 ft |
| Approx Speed Wheel RPM | 400 | 400 | 500 | 540 | 540 |
| Power Required HP | 5 hp | 7.5 hp | 10hp | 15hp | 15hp |
| Approx Wt of Machine-kg | 400 | 525 | 600 | 1100 | 1250 |
