Double Head Riveting Machine
Drill MachinesA Double Head Riveting Machine is a high-efficiency industrial tool used for simultaneously riveting two points on a workpiece. It is widely employed in manufacturing sectors like automotive, electrical appliances, furniture, and hardware assembly, where precision and productivity are crucial.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| MODELS | Riveting capacity (M.S.38kg/mm U.T.S) (mm) | Throat depth (mm) | Shut height (Max) (mm) |
Stroke Adjustable (mm) | Cycle time Adjustable(mm) | Over all dim.(mm) | Motor3 415V | Air Pressure |
| Model-003 | 3 | 110 | 200 | 0-30 | 0-9.9 sec. | 470x400x860 | 0.25 HP (0.18 kw) | 3-7 kg/cm |
| Model-005 | 6 | 110 | 180 | 0-30 | 0-9.9 sec. | 470x400x860 | 0.5 HP (0.37 kw) | 3-7 kg/cm |
| Model-008 | 8 | 140 | 225 | 0-45 | 0-9.9 sec. | 570x525x1100 | 1 HP (0.75 kw) | 3-7 kg/cm |
| Model-012 | 12 | 200 | 280 | 0-45 | 0-9.9 sec. | 625x585x1325 | 1.5 HP (1.2 kw) | 3-7 kg/cm |
| Model-016-H | 16 | 225 | 220 | 0-45 | 0-9.9 sec | 540x615x1375 | 6.0 HP (4.5 kw) Including Power Pack | 0-80 kg/cm (Hydraulic Pressure) |
We have over 20 years of experience in manufacturing double head riveting machines and are committed to offering a solution of efficiency, quality, and large output at a competitive price to our customers. The price of this double head riveting machine is quite affordable and installation cost will be charged from you. This machine can be used for a range of jobs
3D angled front view with all parts labeled for Double Head Riveting Machine
Key Features:
| Dual Riveting Heads: Two heads operate simultaneously or independently to perform riveting at two different points, increasing throughput. |
| Adjustable Head Spacing: The spacing between heads can be adjusted to accommodate various component sizes and riveting distances. |
| Hydraulic or Pneumatic Operation: Available in both hydraulic and pneumatic configurations, depending on the force and precision required. |
| Foot Pedal or Auto Mode: Operators can trigger riveting using a foot pedal, or machines can be programmed for automated cycles. |
| Rigid Frame Structure: Made from cast iron or alloy steel to ensure durability and stability during operation. |
| Precision Guide Rails & Fixtures: For accurate alignment and holding of the components. |
Rollers
Bakelite Metal Assembly
Bicycle Parts
Chain Assembly
Fans
Clutch Brake Liners
Toys
Electronics
Electrical Parts
Castors
Hand Tools
Auto Electricals
Surgical Instruments
Baggage
Locks
Typewriters
Brake shoes
Clutch plates
Seat structures
Busbars
Switchgear panels
Steel chairs
Cabinets
Frames
Hinges
Handles
