Roll Forming Machine to Make Guide U Channels
Other MachinesWe are one of the leading manufacturers of roll forming machines as our products are made with the use of high-quality raw material. Our team has specially designed this machine to manufacture high-quality side channels and U channels for rolling shutters. We have gained the trust of many customers by giving the highest level of customer service.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | RFucl |
| Capacity - Width of Strip | up to 6.5" (165 mm) |
| Capacity - Max. thickness of sheet | 3/32" (2.4 mm) |
| Capacity - Min. thickness of sheet | 1/16" (1.6 mm) |
| Capacity Max. length | no limit |
| Number of Rolls | 8 pairs |
| Machine Speed | 900 Feet / Hour 270 Meters / Hour |
| Motor | 15 HP |
| Net / Gross Weight | 3850 / 4250 kg |
| Dimensions | 3.75 X 1.75 X 1.55 m |
| Shipping Volume | 10 3 |
