Mini Lathe Machine
Lathe MachinesA Mini Lathe Machine is a compact and versatile tool primarily used for small-scale turning, facing, and threading operations on metal, wood, or plastic workpieces. It’s ideal for hobbyists, model makers, small workshops, and educational institutions due to its small footprint and affordable cost.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| Model | TLPM1 |
| Swing over bed | 180 mm |
| Distance between centers | 350 mm |
| Hole through spindle | 20 mm |
| Cross slide travel | 65 mm |
| Compound travel | 55 mm |
| Chuck Dia | 100 mm |
| Swing Dia | 180 mm |
| Spindle taper | MT3 |
| Tailstock taper | MT2 |
| Spindle speed low range | 100-1100 +-10% rpm |
| High range | 100-2500 +- 10% rpm |
| Motor output power | 250 W |
| Range of thread metric version | 0.4-2.0 MM (10 thread pitches) |
| Imperial version | 12-52 TPI (18 thread pitches) |
| Overall dimension (LxWxH) | 700x300x300 mm |
| Weight (Net/Gross) | 42 kg |
| Packing Size | 790x360x390 mm |
The TL Pathak Group presents the Mini Lathe Machine, a compact and versatile tool designed for precision machining in smaller workshops and hobbyist settings. This mini lathe is crafted with precision engineering, allowing users to perform a variety of turning operations on work pieces with ease.Despite its small size, the Mini Lathe Machine by TL Pathak Group features robust construction and high-quality components, ensuring durability and reliable performance. Its user-friendly design includes intuitive controls and easy adjustments, making it suitable for both beginners and experienced machinists,equipped with a powerful motor and precision spindle, this mini lathe offers the capability to turn and shape materials with accuracy. Whether used for crafting small components, prototypes, or intricate projects, the Mini Lathe Machine stands as a testament to TL Pathak Group's commitment to providing efficient and reliable machining solutions for diverse applications.
Key Features
| Size: Typically 7x12", 7x14", or 8x16" |
| Motor Power: 250W to 750W (DC or AC) |
| Spindle Speed: Variable speed, usually 100–2500 RPM |
| Bed Type: Hardened and ground V-bed or flat bed |
| Chuck Size: 3” to 4” three-jaw self-centering chuck |
| Threading Capability: Metric and imperial thread cutting |
| Tool Post: 4-way or quick-change tool post |
| Tailstock: Adjustable with Morse taper for drilling or support |
| Control Panel: Speed control knob, emergency stop, power switches |
3D angled front view with all parts labeled for Mini Lathe Machine
A mini lathe machine is a compact and versatile tool used primarily for machining small workpieces. It is widely used in various fields for precision turning, facing, drilling, cutting, and threading. Below are the key applications and uses of a mini lathe machine:
Uses of Mini Lathe Machine
| Turning Operations | Reducing diameter of a workpiece & Creating cylindrical parts |
| Facing | Producing flat surfaces at the ends of a workpiece |
| Thread Cutting | Making external and internal threads on rods or pipes |
| Drilling | Creating accurate axial holes using a tailstock drill chuck |
| Boring | Enlarging existing holes for precision finishing |
| Knurling | Producing textured patterns on handles or knobs for grip |
| Taper Turning | Creating conical shapes and parts |
| Grooving & Parting | Cutting narrow grooves or separating finished parts from stock |
| Prototyping & Hobby Projects | Ideal for model making, RC parts, jewelry, and small-scale prototyping |
| Educational & Training Use | Teaching fundamental machining techniques in workshops and institutions |
| Educational Institutions – For training students in lathe operations. |
| Jewelry Making – For fine turning and polishing of small components. |
| Watch and Clock Repair – Precise turning of miniature parts. |
| Model Making – Ideal for making components of models and prototypes. |
| Tool Rooms – Used for making and repairing tools. |
| Repair Workshops – Used for turning and threading small parts. |
| Research & Development – Used for experimental setups and prototypes. |
| Dental Laboratories – For shaping and polishing dental tools or models. |
Uses of Bench Lathe Machine:
| Turning small workpieces |
| Facing and drilling operations |
| Thread cutting (external/internal) |
| Taper turning |
| Knurling and grooving |
| Parting-off operations |
| Polishing and buffing small metal parts |
Educational and training institutes
Precision turning of small parts
Making bushings, spacers, pins
Thread cutting and boring
DIY metalworking and model engineering
Watchmaking and Jewelry
