Lathe Machine With Chasing Attachment
Lathe MachinesDownload Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| Parameter | Specification |
| Lathe Bed Type | Heavy-duty, flat bed |
| Center Height | 150 mm to 250 mm |
| Distance Between Centers | 500 mm to 1500 mm |
| Spindle Bore | 25 mm to 52 mm |
| Spindle Speed Range | 40 – 1800 RPM (variable or stepped) |
| Main Motor Power | 1.5 HP to 3 HP |
| Chasing Slide Movement | Manual with micrometer adjustment |
| Thread Types (via Chaser Tool) | Metric, BSW, BA, ACME, Square, Custom |
| Chaser Tool Holding Capacity | Up to 25 mm wide tools |
| Guide Plate (Optional) | Interchangeable for profile replication |
| Tailstock Quill Travel | 100 mm to 150 mm |
| Cross Slide Travel | 150 mm to 250 mm |
| Compound Slide Travel | 100 mm to 150 mm |
| Thread Pitch Range | 0.5 mm to 6 mm (depends on chaser tool) |
| Machine Weight | 600 kg to 1200 kg |
| Power Supply | 415V / 50Hz / 3 Phase |
Our lathe machine with chasing attachment is fitted with heavy-duty tool-post and tailstock, coolant pump, etc. This machine is used to crush, tear, and curl the tea into small hard pellets. This machine is very much affordable. Our experts manufacture this machine with full dedication as they want our customers to be fully satisfied.
Key Components of a Chasing Attachment Lathe:
| Main Lathe Bed – Rigid foundation for all operations. |
| Headstock – Houses the spindle for rotating the workpiece. |
| Tailstock – Supports the free end of the workpiece. |
| Tool Post / Carriage – Holds tools and moves along the bed. |
| Chasing Slide / Attachment – A specialized slide that holds thread chasing tools, typically adjustable. |
| Chasing Tool / Chaser – Tool bits with predefined thread profiles. |
| Guide Plate / Master Thread – Used to guide the chaser tool for replicating threads. |
| 3D angled front view with all parts labeled for Mini Wood Lathe Machine |
| Cross Slide & Compound Slide – For tool movement in transverse directions. |
3D angled front view with all parts labeled for Lathe Machine With Chasing Attachment
Features & Functions:
| Thread Chasing Capability | Used to cut threads without lead screws, using form tools. |
| Custom Profile Replication | Ideal for non-standard or ornamental threads. |
| High Precision | Manual control allows for fine adjustments. |
| Suitable for Small Batches | Especially useful in prototyping and small-lot production. |
A lathe machine with chasing attachment is specially designed for threading operations, particularly ornamental or precision thread cutting on cylindrical surfaces. The chasing attachment allows manual or automatic thread cutting with high accuracy, especially in applications where standard screw-cutting methods are not suitable.
Applications Lathe Machine With Chasing Attachment
| Precision thread cutting |
| Jewelry and ornament making |
| Watch and clock parts manufacturing |
| Fine threading on small components |
| Prototype and model making |
| Instrument and gauge production |
| Repair and custom threading in toolrooms |
| Artistic and decorative turning |
| Threading in soft or brittle materials |
| Restoration of vintage mechanical parts |
Precision screw cutting
Jewelry and bangles thread design
Ornamental wood and metal work
Custom machinery part threading
