Section Bending Economical Series Machine
Section Bending MachineOur economical series comes with a wide range of options. The machines in this series have the best in-house features. It caters to a high range of profiles. It provides better production and faster bending. Our machine in its economic series has the highest capacity with variable speed. We also provide hardened shafts for the machine. And our easy to roll technique is just the best!
From ₹
190,000
To
285,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
Standard Roller
Fiber Rollers
Optional Roller
| Model no | PRBM-300 | PHRBM-300 | PRBM-400 | PHRBM-400 | PHDRBM-400 | PHRBM-500 | PHRBM-600 | PHRBM-700 |
| Round pipe | OD50*3mm | OD50*3mm | OD75*5mm | OD75*5mm | OD75*5mm | OD90*5mm | OD100*5mm | OD120*5mm |
| Square pipe | 50*50*3mm | 50*50*3mm | 75*75*5mm | 75*75*5mm | 75*75*5mm | 90*90*5mm | 100*100*5mm | 100*100*5mm |
| Rectanguler pipe | 60*40*3mm | 60*40*3mm | 80*60*5mm | 80*60*5mm | 80*60*5mm | 90*70*5mm | 100*70*5mm | 110*80*5mm |
| Angle | 50*5mm | 50*5mm | 50*6mm | 50*6mm | 50*6mm | 75*7mm | 90*8mm | 100*10mm |
| T-Angle | 100*10mm | 100*10mm | 100*12mm | 100*12mm | 100*12mm | 150*14mm | 180*16mm | 200*20mm |
| Flat Bar | 50*10mm | 50*10mm | 60*10mm | 60*10mm | 60*10mm | 90*10mm | 100*20mm | 100*20mm |
| Channel | 100*50*5mm | 100*50*5mm | 100*50*6mm | 100*50*6mm | 100*50*6mm | 150*75*5mm | 180*90*8mm | 200*100*10mm |
| Round bar | 25mm | 25mm | 30mm | 30mm | 30mm | 35mm | 40mm | 45mm |
| Square bar | 25*25mm | 25*25mm | 30*30mm | 30*30mm | 30*30mm | 35*35mm | 40*40mm | 45*45mm |
| Motor | 3 HP | 3 HP & 1 HP | 5 HP | 5 HP & 1 HP | 7.5 HP & 3 HP | 7.5 HP & 2 HP | 10 HP & 3 HP | 10 & 5 HP |
| Mechinal jack | YES | NO | YES | NO | NO | NO | NO | NO |
| Hydrualic Cylinder | NO | YES | NO | YES | YES | YES | YES | YES |
| Hrozintal & Vertical | YES | YES | YES | YES | NO | NO | NO | NO |
Square Rectangular Pipe
Solid Round & Squares Bars
Angle Flat Bar
Edged Flat Bar
Solid Round Bars
