Pillar Drill Machine ps-25
Drill MachinesA Pillar Drill Machine also known as a column drill or drilling pillar press is a type of vertical drilling machine mounted on a sturdy pillar or column. It is primarily used for precise and consistent drilling operations in metal, wood, and plastic components.
- High precision and repeatability
- Stable and rigid setup for heavy-duty work
- Adjustable speeds and feeds
- Can accommodate large and heavy workpieces
From ₹
65,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
Motor Pulley
Electric Motor & Starter
Machine Lamp
Coolant Pump With Tank
| Model | PS-25 |
| Titling working table | Fixed |
| Drilling capacity | 25 mm |
| Pilllar diameter | 92 mm |
| Spindle nose to table distance | 660 mm |
| Distance from spindle nose to base distance | 1050 mm |
| Distance from spindle centre to pillar surface (in mm) | 250 (max) |
| Table level | 480 mm |
| Taper in spindle | MT-3 |
| number of speed | 8 speed |
| Range of speed (RPM) | 130 to 2600 |
| Table size (in mm) | 330 x 330 |
| Base size (m/c area in mm) | 365 x 575 |
| Overall base size (in mm) | 370 x 580 |
| Spindle travel | 180 mm |
| Pillar length | 1410 mm |
| Overall height with pulley gurad | 1730 mm |
| V-belt section | B-52" |
| Weight (Approx) | 225 kgs |
| Motor 1440 RPM 3 Phase 440 Volts | 1 H.P |
| Shipping wooden case | 860x450 |
| Inner size LxWxH | 1770 mm |
We are known for providing the best to our customers as we always check our products before providing them. The main spindle and pinion of our 25 mm pillar drill machine are made from EN steel. This machine is not that much costly as its price range are affordable. We assure our customers to provide quality assured material to make our machines long-lasting.
Key Features
| Vertical Column: Supports the drilling head and allows vertical movement. |
| Base/Table: Flat, stable surface to place the workpiece; adjustable height and rotation. |
| Drill Head: Contains the motor and spindle; moves up and down via a hand lever or automatic feed. |
| Chuck and Spindle: Holds and rotates the drill bit. |
| Motor: Powers the spindle with adjustable speed options. |
| Depth Stop: Controls drilling depth for consistent holes. |
Tool Rooms
Educational Institutes
Workshops
Small & Medium Scale Industries
Precision drilling
Fabrication units
Drilling metal
Drilling wood
Drilling plastic
