Automatic Hydraulic Degree Pipe Bending Machine
Section Bending MachineAn automatic Hydraulic pipe bending machine is the best machine for all your industrial works. It has varied use in different types of industries. It has an NC based system and operates to give the most accurate results. It can even be used for store display equipment. This hydraulic machine is designed in such a way as to provide the best-automated experience.
From ₹
350,000
To
845,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
Encoder Based Degree counter System
Fully NC Based System
| Model Name | ROUND PIPE | SQUARE PIPE | ROUND BAR | SQUARE BAR | MOTOR | MOTO RISE | HYDRAULIC | CYLINDER NOS |
| PMBM 1.5''-2 MM | OD 38*2mm | 38*38*2mm | 15mm | 15*15mm | 2 HP | YES | NO | NO |
| PMBM 2''-3 MM | OD 50*3mm | 50*50*3mm | 18mm | 18mm | 3 HP | YES | NO | NO |
| PHBM 2''- 3 MM | OD 50*3mm | 50*50*3mm | 18mm | 18mm | 3 HP | NO | YES | 1 NOS |
| PHBM 2''-5 MM | OD 50*5mm | 50*50*3mm | 20mm | 20mm | 5 HP | NO | YES | 1 NOS |
| PHBM 2.5''-5 MM | OD 63*5mm | 63*63*5mm | 25mm | 25mm | 5 HP | NO | YES | 1 NOS |
| PHBM 3''-5 MM | OD 76*5mm | 76*76*5mm | 28mm | 28mm | 7.5 HP | NO | YES | 1 NOS |
| PHCBM 2''-3 MM | OD 50*3mm | 50*50*3mm | 18mm | 18mm | 3 HP | NO | YES | 3 NOS |
| PHCBM 2''-5 MM | OD 50 5mm | 50*50*3mm | 20mm | 20mm | 5 HP | NO | YES | 3 NOS |
| PHCBM 2.5''-5 MM | OD 63*5mm | 63*63*5mm | 25mm | 25mm | 5 HP | NO | YES | 3 NOS |
| PHCBM 3''-5 MM | OD 76 5mm | 76*76*5mm | 28mm | 28mm | 7.5 HP | NO | YES | 3 NOS |
| PHCBM3.5''- 5 MM | OD 90*5mm | 90*90*5mm | 35mm | 35mm | 7.5 HP | NO | YES | 3 NOS |
| PHCBM 4''-5 MM | OD 114*5mm | 110*110*5mm | 40mm | 40mm | 10 HP | NO | YES | 3 NOS |
Automotive
Building Construction
Boiler Tubes
Chemical Plants
Electrical Appliances
Furniture
Gymnasium Equipment
Irrigation System
Material Handing Equipment
Stores Display Equipment
