Mini CNC Milling
Milling MachinesAdvantages:
- Affordable compared to industrial CNC milling machines.
- Easy to set up and operate.
- Suitable for beginners as well as professional machinists.
- Saves time and material with precise automation.
Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
| Model Name | TLPMCM 400 |
| Worktable Size | 400x140 mm |
| T-Slots Size | 40 mm |
| X Axis Travel | 210 mm |
| Y Axis Travel | 120 mm |
| Z Axis Travel | 200 mm |
| Max. Drilling Dia | 16 mm |
| Max. Milling Dia | 16 mm |
| Max. Tapping Dia | M8 |
| Distance from Spindle Center to Column | 194 mm |
| Distance from Spindle Nose to Worktable Surface | 215 mm |
| Spindle Speed | 3000 RPM |
| Spindle Taper | ER25 |
| Spindle Power | 1.2 K.W. |
| Main Motor Type | Servo Motor |
| Feeding Motor Torque (X/Y/Z) | 2.0/2.0/3.0 N.m. |
| Feeding Motor Type | Stepper Motor |
| Overall Size (LxWxH) | 1150x650x1560 mm |
| Net Weight | 310 kg |
| Gross Weight | 330 kg |
TL Pathak Group's Mini CNC Milling Machine is a compact marvel, combining precision and efficiency for small-scale machining. This versatile machine boasts a high-speed spindle and advanced CNC controls, enabling intricate and accurate milling operations. Designed for constrained spaces, it excels in applications demanding fine detail and tight tolerances. The Mini CNC Milling Machine from TL Pathak Group ensures optimal performance, allowing users to achieve superior results in a variety of materials. Its user-friendly interface simplifies programming, making it accessible for both beginners and experienced operators. With a robust structure and reliable components, this machine is an ideal choice for industries requiring precision in limited workspaces, showcasing TL Pathak Group's commitment to delivering innovative solutions for modern manufacturing challenges.
3D angled front view with all parts labeled for Mini CNC Milling
Key Features:
| Compact Design Small footprint, suitable for limited workspace. |
| High Precision Controlled by CNC software for accurate and repeatable machining. |
| Multi-Axis Capability Typically 3-axis, with some models supporting 4th axis attachments. |
| Versatile Material Handling Can work on aluminum, brass, mild steel, plastics, and composites. |
| User-Friendly Control Panel Equipped with a digital display and keypad for programming. |
| Enclosed Structure Provides operator safety, reduces noise, and contains chips/coolant. |
Educational Institutes
Small & Medium Scale Industries
Diamond & Jewellery Industries
Automotive Industry
