Horizontal Double Column Bandsaw Machine Model-175 S.A.
Cutting MachinesThe horizontal bandsaw 175 S.A is a heavy-duty cutting machine manufactured by TL Pathak Group in India. This machine is designed for precision cutting of various materials, including metal, wood, and plastics, and features a sturdy construction and advanced cutting technology.
The 175 S.A has a cutting capacity of up to 175mm, making it an ideal choice for industrial applications that require high-volume cutting of large materials. It also features an advanced control system that allows for easy adjustment of cutting speed and blade tension, ensuring precise and accurate cuts every time.
This machine also comes equipped with a hydraulic feeding system that ensures smooth and consistent feeding of materials, reducing the risk of blade damage and increasing productivity. With its high-quality blade and user-friendly design, the horizontal bandsaw 175 S.A is a reliable and efficient cutting solution for industrial settings. TL Pathak Group is committed to providing innovative and high-quality cutting solutions to its customers, and the 175 S.A is a testament to this commitment.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | 175 S | 175 S.A. | 175 H.L.C. |
| Cutting Capacity Round Bar(mm) | 175 | 175 | 175 |
| Square(mm) | 160x160 | 160x160 | 160x160 |
| Blade Size(mm) | 27x0.9x2515 | 27x0.9x2515 | 27x0.9x2515 |
| Motor power | 1 H.P./1440 RPM | 1 H.P./1440 RPM | 1 H.P./1440 RPM |
| Coolant Pump Power | 0.15 H.P./2800 RPM | 0.15 H.P./2800 RPM | 0.15 H.P./2800 RPM |
| Hydraulic Drive Motor | x | 0.25 H.P./1500 RPM | 0.25 H.P./1500 RPM |
| Cutting Speed Control | Power Hydraulic | Power Hydraulic | Power Hydraulic |
| Blade Speed Min/Mtr | 32/42 | 32/42 | 32/42 |
| Net Weight | 210 kg | 210 kg | 210 kg |
| Overall Dimension | 1150x500x1400(LxWxH) | 1150x500x1400(LxWxH) | 1150x500x1400(LxWxH) |
