Double Body Fly Press

Press Machines
Pathak has become a leading brand providing high-quality Double body fly press machines available with different specifications as per standard and custom requirements of clients according to their industries. Its quality guarantees you durability, which increases output and your profit. It is made with a rigid structure and fulfils all requirements of its buyers.
From ₹
19,000

Download Catalog Request Catalog

Order By Phone

Shipping Information Usually dispatched With In business days

+91-9124009247 OR Call Me Back
Double body fly press 6 8 10
No of size Inch mm Inch mm Inch mm
Base to guide 9 229 10 250 11 279
Between Uprights 12 305 14 356 17 432
Hole through base (without ring) 4 1/2 114 6 152 8 203
Hole through base (without ring) 2 1/4 57 3 76 4 102
Stroke 7 178 8 204 9 228
Diameter of screw 2 5/6 62 3 76 3 3/8 89
Hole in ram (Dia) 1 25 1 1/4 32 1 1/4 32
Hole in ram (Depth) 2 51 2 1/2 64 2 1/2 64
Total weight of Machine 375 KG 500 KG 674 KG
