Cross Shaft C Frame Power Press
Press MachinesPathak Manufacturing best quality Cross Shaft C Frame Power press machine available in a wide range mainly designed automatic or hand-fed general stamping applications such as blanking, piercing, forming, drawing, bending, etc., with efficient work capacity, and it's made with premium quality raw material, which ensures its long life and made using advanced technologies.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Capacity Tons | 32 | 40 | 63 | 80 | 100 | 160 | 200 | 250 | |
| Table Size | 630 x 400 | 800 x 450 | 850 x 500 | 960 x 570 | 1000 x 625 | 1120 x 650 | 1250 x 800 | 1250 x 800 | |
| Slide Area L-RxF-B | 350 x 250 | 400 x 325 | 500 x 400 | 500 x 400 | 625 x 425 | 700 x 590 | 875 x 775 | 900 x 775 | |
| Day Light (SUAU) | 330 | 340 | 400 | 420 | 450 | 560 | 650 | 675 | |
| Stroke Length Fix | 60 | 60 | 100 | 100 |
125 | 160 | 200 | 200 | |
| Stroke Length (Adj) | 8-60 | 8-60 | 8-100 | 8-100 | 8-125 | 8-160 | 200 | 200 | |
| Slide Adjustment | 63 | 63 | 70 | 70 | 80 | 100 | 100 | 125 | |
| Shut Height (SDAU) | 270 | 280 | 300 | 320 | 325 | 400 | 450 | 475 | |
| Nos of Slide Strokes (SPM) | 50 | 50 | 50 | 50 | 45 | 40 | 40 | 35 | |
| Fly Wheel Energy (KJ) | 4-4 | 8 | 16.75 | 20 | 25 | 55 | 70 | 80 | |
| Height from Floor to Top | 800 | 850 | 856 | 850 | 850 | 900 | 900 | 900 | |
| Main Motor (HP) | 3 | 5 | 7.5 | 7.5 | 10 | 20 | 20 | 25 | |
| Req.air pressure for pneumatic clutch (Kg/cm2) | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | 5.5 | |
| Optional Die Cushion | Capacity | 1.7 | 4.5 | 70 | 80 | 100 | 200 | 200 | 270 |
| Stroke | 50 | 50 | 50 | 50 | 50 | 75 | 100 | 100 | |
| Alr Pressure (Kg/Cm2) | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | |
