Knukle Joint Press Machine
Press MachinesProviding the best quality knuckle joint press machine made with the latest technology under the supervision of our skilful team available with the latest features. Mainly used in connecting rods of locomotive wheels, in the bicycle chains, chain straps of watches and in producing coins and medals at high speed. The machine works with total efficiency and is made with the best quality raw material.
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| Model | PKJ - 250 | PKJ - 400 | |
| CAPACITY | TON | 250 | 400 |
| RATED TONNAGE POINT | MM | 4 | 6 |
| STROKE LENGTH | MM | 120 | 160 |
| STROKE PER MINUTE | 50 | 40 | |
| DIE HEIGHT (S.D.A.U) | MM | 370 | 400 |
| BOLSTER AREA (L.RXF.B) | MM | 500x600 | 500x600 |
| SLIDE AREA (L.RXF.B) | MM | 400x200 | 400x500 |
| SLIDE ADJUSTMENT | MM | 15 | 15 |
| BOLSTER THICKNESS | MM | 100 | 120 |
| KEEP THE AIR PRESSURE | KG/CM2 | 5 | 5 |
| UPPER EJECTOR | CAPACITY TON | 5 | 7.5 |
| STROKE MM | 25 | 30 | |
| PIN DIA MM | 40 | 50 | |
| TYPE - | Mechanical | Mechanical | |
| CAPACITY TON | 10 | 15 |
