Bench Drill Machine-pd-13
Drill MachinesA Bench Drill Machine, also known as a Bench Top Drill Press, is a compact and precise drilling machine designed to be mounted on a workbench. It is ideal for light- to medium-duty drilling tasks and is widely used in workshops, tool rooms, and educational labs.
- Compact and space saving
- Affordable and easy to use
- Offers high drilling precision
- Suitable for detailed and repetitive work
From ₹
20,000
To
35,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-8035735963 OR Call Me Back
Drilling Machine With Magnetic Stand
| ARTICULARS | PD-12 |
| Drilling capacity in Steel | 13mm |
| Spindle Taper | JT-6/MT-2 |
| Spindle Travel | 87 |
| Pillar Diameter | 48 |
| Pillar Length | 625 |
| Distance btw center of spindle & pillar front | 150 |
| Max Distance btw Spindle & Table | 250 |
| Max Distance btw Spindle & Base | 363 |
| Table working space | 200 |
| Base Working Surface (Machined) | 175x175 |
| Overall size of base | 320x320 |
| No of Spindle Speeds | 4 |
| Range of Spindle Speeds (r p m) | 640-1040-1640-2540 |
| V Belt | A 36 |
| Motor | 1/2 H.P |
| Net Weight | 45Kg |
| Space Occupied (LxBxH) | 390x300x815 |
Our team has especially designed this machine that is handled and operated by hands only. It is very easy to operate that anyone can use it even with a piece of less knowledge. Its cost ranges are affordable and do not even require any maintenance cost. you can even drill anything in a short duration of time with its high frequency of 50hz.
Key Components
| Base Plate: Provides stability and is mounted on the workbench. |
| Column: Supports the head and allows the table to move vertically. |
| Drill Head: Houses the motor and spindle mechanism. |
| Spindle & Chuck: Holds the drill bit and performs the cutting operation. |
| Table: Adjustable platform for positioning workpieces; can tilt/rotate. |
| Feed Handle: Manually lowers the spindle to initiate drilling. |
| Depth Stop: Controls and limits drill depth for precision. |
Tool Rooms
Workshops
Small & Medium Scale Industries
Fabrication Workshops
Precision drilling
Fabrication units
Drilling metal
Drilling wood
Drilling plastic
