Round Die Roll Threading Machine 25 mm
Threading MachinesWe also deal in Round Die Roll Threading Machine 25 mm and have various good reviews about the quality of the machines. There are also different designs and ranges available for customers. You will get a hundred percent genuine and qualitative machines if you deal with us.
From ₹
380,000
To
565,000
Download Catalog Request Catalog
Order By Phone
Shipping Information Usually dispatched With In business days
+91-9124009247 OR Call Me Back
| TWO ROLL TYPE | RTD - 25 | RTD - 40 | RTD - 50 | RTD - 80 | RTD - 100 | RTD - 120 |
| Max.Pitch Can Be Rolled (In Mm) | 2.5 | 3.5 | 4 | 5 | 5.5 | |
| Max.Dia Can Be Rolled in Feed (In Mm) | 25 | 40 | 50 | 80 | 100 | 120 |
| Max.Dia Can Be Through Feed (In Mm) | 18 | 28 | 35 | 40 | 50 | 70 |
| Max. Rolling Length In Feed (In Mm) | 80 | 100 | 150 | 150 | 150 | 150 |
| Max.Rolling Length Through Feed | indefinite | indefinite | indefinite | indefinite | indefinite | indefinite |
| Max.Outer Dia Thread Rolls (In Mm) | 120 | 180 | 180 | 180 | 200 | 220 |
| Spindle Dia (Bore Dia) (In Mm) | 40 | 54 | 54 | 69.85 | 76.20 | 76.20 |
| Max.Width Thread Rolls (In Mm) | 80 | 100 | 140 | 150 | 150 | 150 |
| Max.Rolling Force | 8 Tons | 12Tons | 15Tons | 24Tons | 30Tons | 40Tons |
| Power For Roll Spindles | 3 H.P. 1440 RPM | 5 H.P. 1440 RPM | 7.5 H.P. 1440 RPM | 10 H.P. 1440 RPM | 12.5 H.P. 1440 RPM | 20 H.P. 1440 RPM |
| Power For Hydraulic Pump | 2 H.P./3H.P. 960/1440 RPM | 2 H.P./3H.P.960/1440 RPM | 5 H.P. 960/1440 RPM | 5 H.P./7.5H.P 960/1440 RPM | 5 H.P./7.5H.P 960/1440 RPM | 7.5 H.P.960/1440 RPM |
